Electric single drum anchor machine is a device installed on ships for anchoring and anchoring. It is mainly powered by an electric motor and driven to rotate a single drum through a transmission device. When the anchor is lifted, the motor rotates forward, driving the drum to wrap around the anchor chain and pull the anchor up from the bottom of the water; When anchoring, the motor reverses and the reel releases the anchor chain, causing the anchor to sink to the bottom of the water.
| Main techinical specification | |||
| Rated Pull(kN) | Rated Speed(m/min) | Drum Capacity(m) | Motor Power(kW) |
| 10 | ≥12 | Ф10х150 | 5.5 |
| 20 | ≥12 | Ф15х150 | 11 |
| 30 | ≥15 | Ф17х150 | 15 |
| 40 | ≥15 | Ф18х150 | 22 |
| 50 | ≥15 | Ф20.5х150 | 30 |
| 75 | ≥15 | Ф26х200 | 45 |
| 80 | ≥15 | Ф26х200 | 45 |
| 100 | ≥15 | Ф30х200 | 45 |
| 125 | ≥15 | Ф30х200 | 75 |
| 160 | ≥15 | Ф32х250 | 75 |
| 200 | ≥9.6 | Ф41х250 | 75 |
| 560 | ≥6 | Ф64х250 | 132 |
| 600 | ≥6 | Ф64х250 | 132 |
| 650 | ≥6 | Ф70х250 | 132 |
| 1000 | ≥4 | Ф85х250 | 132 |
| 1200 | ≥4 | Ф95х250 | 160 |
| 1500 | ≥4 | Ф95х250 | 200 |
| 1800 | ≥4 | Ф95х250 | 250 |
| 2000 | ≥4 | Ф100х250 | 270 |
Product Detail:
1. Material: Steel
2. Customize according to customer requirements
3. Certificate: CCS, ABS, LR, GL, NK, RS, DNV, KR, BV, RINA
