| Product No. | Bolts Qty | Capacity (Tonnes) | Dimensions(mm) | |||||||
| A | B | C | D | E | F | G | H | |||
| N-001 | 4 | 10 | 200 | 216 | 236 | 160 | 106 | 218 | 120 | 32 |
| N-002 | 4 | 25 | 245 | 350 | 305 | 250 | 150 | 285 | 127 | 45 |
| N-003 | 5 | 80 | 415 | 518 | 540 | 430 | 250 | 430 | 245 | 55 |
| N-004 | 7 | 120 | 490 | 678 | 642 | 600 | 330 | 584 | 290 | 65 |
| N-005 | 7 | 200 | 520 | 950 | 780 | 680 | 360 | 670 | 306 | 80 |
| N-006 | 7 | 200 | 600 | 950 | 780 | 680 | 360 | 670 | 386 | 80 |
| N-007 | 6 | 200 | 656 | 1020 | 930 | 800 | 460 | 830 | 349 | 100 |
Product Detail:
1. Strong and durable design;
2. Material: cast steel, cast iron, ductile iron;
3. Surface: polished, galvanized, smooth,anti-corrosion;
4. Certificate: CCS, ABS, BV, LR etc.;
5. Custom made according to customer’s drawing;
