| Nominal Dia. | Wire Rope Max. Dia. | Hemp Rope Max. Dia. | Synthetic Carbon Fiber Rope Max. Dia. | D | D1 | B | H | h | h1 | t | d | d1 | r | A | Screws | Weight(kg) | |
| Screw Thread Dia. | Quantity(piece) | ||||||||||||||||
| 50 | 8.7 | 75 | 16 | 50 | 65 | 135 | 190 | 8 | 85 | 6 | 25 | 35 | 25 | 85 | M16 | 4 | 2.8 |
| 75 | 11.5 | 90 | 20 | 75 | 75 | 185 | 290 | 12 | 135 | 7 | 42 | 52 | 35 | 115 | M22 | 4 | 8 |
| 100 | 13.5 | 100 | 24 | 100 | 100 | 235 | 350 | 18 | 160 | 7 | 50 | 65 | 40 | 155 | M27 | 4 | 15 |
Product Details:
1. Material: Casting Steel, Casting iron
2. Nominal Diameter: 50mm,75mm,100mm;
3. Certificate: CCS, ABS, LR, GL, DNV, NK, BV, KR, RINA, RS etc.
